n8n Deployment: Kubernetes Manifest Guide

Part 2 of 3. Part 1: Docker Compose Setup | Part 3: Configuration Deep Dive

Kubernetes Deployment

When I move n8n into a production cluster, I use Kubernetes with Helm-like manifests managed through GitOps. The following manifests assume you have a running cluster with an ingress controller and cert-manager for TLS.

Step 1: Namespace and Secrets

apiVersion: v1
kind: Namespace
metadata:
  name: n8n

apiVersion: v1
kind: Secret
metadata:
  name: n8n-secrets
  namespace: n8n
type: Opaque
stringData:
  postgres-password: "<GENERATE_32_CHAR_PASSWORD>"
  encryption-key: "<GENERATE_32_CHAR_KEY>"
  basic-auth-user: "admin"
  basic-auth-password: "<GENERATE_24_CHAR_PASSWORD>"

Apply with kubectl apply -f namespace.yaml -f secret.yaml.

Step 2: PostgreSQL StatefulSet

apiVersion: apps/v1
kind: StatefulSet
metadata:
  name: postgres
  namespace: n8n
spec:
  serviceName: postgres
  replicas: 1
  selector:
    matchLabels:
      app: postgres
  template:
    metadata:
      labels:
        app: postgres
    spec:
      containers:
      - name: postgres
        image: postgres:16-alpine
        env:
        - name: POSTGRES_USER
          value: "n8n"
        - name: POSTGRES_PASSWORD
          valueFrom:
            secretKeyRef:
              name: n8n-secrets
              key: postgres-password
        - name: POSTGRES_DB
          value: "n8n"
        ports:
        - containerPort: 5432
        volumeMounts:
        - name: postgres-data
          mountPath: /var/lib/postgresql/data
        resources:
          requests:
            memory: "256Mi"
            cpu: "250m"
          limits:
            memory: "1Gi"
            cpu: "1000m"
  volumeClaimTemplates:
  - metadata:
      name: postgres-data
    spec:
      accessModes: ["ReadWriteOnce"]
      resources:
        requests:
          storage: 10Gi
---
apiVersion: v1
kind: Service
metadata:
  name: postgres
  namespace: n8n
spec:
  selector:
    app: postgres
  ports:
  - port: 5432
    targetPort: 5432

Step 3: Redis Deployment

apiVersion: apps/v1
kind: Deployment
metadata:
  name: redis
  namespace: n8n
spec:
  replicas: 1
  selector:
    matchLabels:
      app: redis
  template:
    metadata:
      labels:
        app: redis
    spec:
      containers:
      - name: redis
        image: redis:7-alpine
        command:
        - redis-server
        - --appendonly
        - "yes"
        - --maxmemory
        - "256mb"
        - --maxmemory-policy
        - "allkeys-lru"
        ports:
        - containerPort: 6379
        volumeMounts:
        - name: redis-data
          mountPath: /data
        resources:
          requests:
            memory: "128Mi"
            cpu: "100m"
          limits:
            memory: "512Mi"
            cpu: "500m"
      volumes:
      - name: redis-data
        emptyDir: {}
---
apiVersion: v1
kind: Service
metadata:
  name: redis
  namespace: n8n
spec:
  selector:
    app: redis
  ports:
  - port: 6379
    targetPort: 6379

Step 4: n8n Main Deployment

apiVersion: apps/v1
kind: Deployment
metadata:
  name: n8n-main
  namespace: n8n
spec:
  replicas: 1
  selector:
    matchLabels:
      app: n8n-main
  template:
    metadata:
      labels:
        app: n8n-main
    spec:
      containers:
      - name: n8n
        image: n8nio/n8n:1.50
        ports:
        - containerPort: 5678
        env:
        - name: DB_TYPE
          value: "postgresdb"
        - name: DB_POSTGRESDB_HOST
          value: "postgres"
        - name: DB_POSTGRESDB_PORT
          value: "5432"
        - name: DB_POSTGRESDB_DATABASE
          value: "n8n"
        - name: DB_POSTGRESDB_USER
          value: "n8n"
        - name: DB_POSTGRESDB_PASSWORD
          valueFrom:
            secretKeyRef:
              name: n8n-secrets
              key: postgres-password
        - name: EXECUTIONS_MODE
          value: "queue"
        - name: QUEUE_BULL_REDIS_HOST
          value: "redis"
        - name: QUEUE_BULL_REDIS_PORT
          value: "6379"
        - name: N8N_ENCRYPTION_KEY
          valueFrom:
            secretKeyRef:
              name: n8n-secrets
              key: encryption-key
        - name: WEBHOOK_URL
          value: "https://n8n.yourdomain.com/"
        - name: GENERIC_TIMEZONE
          value: "UTC"
        - name: N8N_BASIC_AUTH_ACTIVE
          value: "true"
        - name: N8N_BASIC_AUTH_USER
          valueFrom:
            secretKeyRef:
              name: n8n-secrets
              key: basic-auth-user
        - name: N8N_BASIC_AUTH_PASSWORD
          valueFrom:
            secretKeyRef:
              name: n8n-secrets
              key: basic-auth-password
        resources:
          requests:
            memory: "512Mi"
            cpu: "500m"
          limits:
            memory: "2Gi"
            cpu: "2000m"
---
apiVersion: v1
kind: Service
metadata:
  name: n8n-main
  namespace: n8n
spec:
  selector:
    app: n8n-main
  ports:
  - port: 5678
    targetPort: 5678

Step 5: n8n Workers

apiVersion: apps/v1
kind: Deployment
metadata:
  name: n8n-worker
  namespace: n8n
spec:
  replicas: 3
  selector:
    matchLabels:
      app: n8n-worker
  template:
    metadata:
      labels:
        app: n8n-worker
    spec:
      containers:
      - name: n8n
        image: n8nio/n8n:1.50
        command: ["n8n", "worker"]
        env:
        - name: DB_TYPE
          value: "postgresdb"
        - name: DB_POSTGRESDB_HOST
          value: "postgres"
        - name: DB_POSTGRESDB_PASSWORD
          valueFrom:
            secretKeyRef:
              name: n8n-secrets
              key: postgres-password
        - name: QUEUE_BULL_REDIS_HOST
          value: "redis"
        - name: QUEUE_BULL_REDIS_PORT
          value: "6379"
        - name: N8N_ENCRYPTION_KEY
          valueFrom:
            secretKeyRef:
              name: n8n-secrets
              key: encryption-key
        - name: GENERIC_TIMEZONE
          value: "UTC"
        resources:
          requests:
            memory: "256Mi"
            cpu: "250m"
          limits:
            memory: "1Gi"
            cpu: "1000m"

Step 6: Ingress with TLS

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: n8n
  namespace: n8n
  annotations:
    cert-manager.io/cluster-issuer: "letsencrypt-prod"
    nginx.ingress.kubernetes.io/ssl-redirect: "true"
spec:
  ingressClassName: nginx
  tls:
  - hosts:
    - n8n.yourdomain.com
    secretName: n8n-tls
  rules:
  - host: n8n.yourdomain.com
    http:
      paths:
      - path: /
        pathType: Prefix
        backend:
          service:
            name: n8n-main
            port:
              number: 5678

Apply all manifests:

kubectl apply -f namespace.yaml -f secret.yaml -f postgres.yaml -f redis.yaml -f n8n-main.yaml -f n8n-worker.yaml -f ingress.yaml

Verify the rollout:

kubectl get pods -n n8n
kubectl logs -n n8n deployment/n8n-main | grep "Editor is now accessible"

Webhook Security

Webhooks are the most exposed surface of any automation platform. Here is how I lock them down.

Use a Dedicated Webhook Subdomain

I always separate the webhook ingress from the editor UI. If your main instance is at n8n.yourdomain.com, run webhooks on hooks.yourdomain.com. This lets you apply different rate limits, WAF rules, and authentication policies.

Enable Webhook Authentication

n8n supports basic auth and header-based auth on webhook workflows. For production webhooks, I add a custom header check:

// n8n Webhook node → Headers
{
  "X-Webhook-Secret": "{{$env.WEBHOOK_SECRET}}"
}

Store WEBHOOK_SECRET in the n8n credentials vault, not in the workflow JSON.

IP Allowlisting

If your webhooks only receive events from known sources (GitHub, Stripe, etc.), restrict ingress by source IP:

# nginx ingress annotation
nginx.ingress.kubernetes.io/whitelist-source-range: "192.30.252.0/22, 185.199.108.0/22"

Credential Management

n8n encrypts credentials at rest using the N8N_ENCRYPTION_KEY. However, there are additional layers you should add.

Layer	Implementation	Risk Mitigated
Encryption at rest	`N8N_ENCRYPTION_KEY`	Database theft
Encryption in transit	TLS on ingress	Man-in-the-middle
Secret injection	Kubernetes Secrets / Docker Secrets	Credential leakage in env
Access control	n8n RBAC + basic auth	Unauthorized workflow edits
Audit logging	PostgreSQL query logs	Credential access tracing

I rotate the encryption key quarterly. To do this, export all workflows, destroy the volume, start n8n with a new key, and re-import. It is tedious but necessary for high-security environments.

AI Agent Node Setup

n8n’s AI Agent node lets you build agentic workflows that can call tools, reason over context, and interact with LLMs. I use this to build self-healing infrastructure alerts and automated ticket triage.

Connecting to a Self-Hosted LLM

If you followed my Ollama deployment guide, you already have a local LLM running. Wire it into n8n like this:

Add an HTTP Request node or use the Ollama Chat Model node (community node).
Set the base URL to your Ollama instance: http://ollama.ai-serving.svc.cluster.local:11434.
Select the model: llama3.1:8b or mistral:7b.
For the AI Agent node, set the System Message to define the agent’s role:

You are an SRE assistant. You have access to Kubernetes logs, deployment statuses,
and alerting history. When asked about an incident, summarize the symptoms,
suggest root causes, and recommend the next diagnostic step. Do not execute
commands without explicit approval.

Basic Workflow: Alert → LLM → Slack

Here is a simple workflow I run for triaging Prometheus alerts:

Webhook Trigger: Receives alert payload from Alertmanager.
HTTP Request: Fetches recent logs from Loki for the affected service.
AI Agent: Summarizes logs and suggests a root cause.
Slack: Posts the summary to #incidents with approve/reject buttons.
If Approved: A second branch runs a safe diagnostic (e.g., kubectl get events).

This keeps humans in the loop while automating the noise reduction that usually burns out on-call engineers.

FAQ

What is n8n and what makes it different from Zapier?

n8n is an open-source workflow automation platform. The key difference from Zapier: you self-host everything. Your data never touches third-party servers, credentials stay encrypted on your infrastructure, and there are no usage tiers limiting how many workflows you can run. I switched to n8n after Zapier changed their pricing model and my automation bill tripled overnight.

How do I scale n8n workers on Kubernetes?

Set the replicas field in the n8n-worker Deployment manifest. I start with 3 replicas and scale based on Redis queue depth. Monitor LLEN bull:jobs in Redis. When it stays above 100 for more than 5 minutes, I add more workers. Each worker needs at least 256Mi RAM and 250m CPU for basic workflows.

Can I use n8n with vLLM instead of Ollama?

Yes. Both Ollama and vLLM expose OpenAI-compatible APIs. Point the HTTP Request node or the OpenAI Chat Model node at your vLLM service URL and set the model name. I run Ollama for development and vLLM for production workloads.

How do I back up my n8n instance on Kubernetes?

Back up two things: the PostgreSQL database (pg_dump) and the encryption key. Without the N8N_ENCRYPTION_KEY, your credentials are unrecoverable. I run nightly pg_dumps to S3-compatible storage and store the encryption key in a secure vault.

What is queue mode and when do I need it?

Queue mode separates the web UI from workflow execution workers using Redis as a job queue. I enable queue mode as soon as I have more than 5 active workflows. Without it, a single slow workflow can block the entire execution pipeline.

Is the n8n AI Agent node production-ready?

For internal tooling and alert triage, yes. I would not trust it for autonomous remediation in production without human approval gates. Always keep a human in the loop for destructive actions like deleting resources or modifying deployments.
